Custom EURO Fat 250 Pro-Street LSD Rolling Chassis Kit
The coolest Euro-Style ProStreet Rigid Rolling Chassis
with
'60 SPOKES'
CHROME CHOPPER RIMS
with BILLET HUBS
All New High Line Show Quality Custom Parts
This is not a backyard package. This is top of the line stuff!
List of parts included in this kit:
250 Wide Drop-Seat
LSD ProStreet Frame
"Extreme Euro Design"
True Custom!
Nice Pro-Street Drop-Seat Rigid frame.
Brand new first quality Frame with MSO.
This USA made wide tire frame
FITS FAT TIRE 250
LEFT SIDE DRIVE
HEAVY DUTY FRAME
Specical Features include:
42° Degree Rake. (Will work with 2" over front end.)
6" Stretch on Back Bone.
0" Stetch on Single Downtube.
Single Heavy Duty Downtube.
1-3/8" tube with 156 wall.
CNC Milled motor mount.
TIG welded at major points.
MIG welded on our new precision frame fixtures for accurate location & fitment.
Accepts any Harley-Davidson Evolution motor 88"-135".
Motor mounts.
Rear axle and plates included.
This frame is for chain drive only (too long for a belt)
accepts any Harley-Davidson Evo Big Twin engine except Twin Cam 88
included rear axle, custom battery tray, oil tank, billet oil cap.
Frame includes a Manufacturer s Statement of Origin (MSO) for registration
(will be shipped separately for safety).
$3499 Retail.
'60 Spoke'
Chrome with Billet Hub 18" x 8.5" Rear Wheel
Will fit 250 Tire
$1050 Retail
'60 Spoke'
Chrome with Billet Hub Front 21" x 2.15" Wheel
$850 Retail
3" Stretched Gas Tank with Pop-Up Cap
$610 Retail
Chrome Billet Front End (Custom Smooth Style)
$1999 Retail
Total Retail:$8,008.00 plus tax.
You are getting all of the parts listed above.
You are buying a $8K rolling chopper chassis. Don't miss out on our deal!
All our Big Twin rolling chassis will fit 84-99 Evo style H-D engine, Ultima engine, S&S engine, RevTech engine, Merch engines, Patric engines and and and all Evo styles.
You can also fit a Shovelhead engine with no problems, Twin Cam engines can easy be custom fitted with a Twin Cam adapter plate that we also offer in our listing.
Thanks, and have fun building your dream bike.
Chopper built on this frame.
Chopper built on this frame
