Dimaond Motorcycle Chain 530 100 Link for Standard Harley-Davidson Frames

DIAMOND Motorcycle Chain
Nothing outlasts a Diamond!

For standard Harley-Davidson frames

530 RIV 100P

Performance
Powersports Chain

The coverside pitch holes are designed for semi-press fit on the pins and should never be altered. Press the coverside on the pins and install the "UNSPRUNG HERO" clip. Be sure the clip opening is trailing. Tap the connecting link pin ends gently. This positions the clip snug against the coverside which will lend support to the clip. This prevents the possibility of a tight joint due to the coverside being squeezed on too far. Refer to the owners manual or dealer shop manual for tension and alignment recommendations.

Attach "UNSPRUNG HERO" clip with the clip opening trailing the direction of travel

POWERSPORT STANDARD SERIES

INSTRUCTIONS

WHEN DISASSEMBLING DR ASSEMBLING CHAINS:

WARNING - The components of a chain are hardened parts. Striking these parts may cause metal chips to break off from the chain or the tools used resulting in personal injury. During all stages of chain disassembly and assembly, wear safety glasses to prevent metal parts or chips from entering your eyes and have personnel in the immediate area do likewise.
A. Pin Removal
1. If chain is of cotterpin-type construction, remove cotters.
2. If chain is riveted-type construction, grind pin heads off so pin ends are flush with the linkplate.
3. Drive pins out of Iinkplate using a Diamond Pin Extractor Model# 113 or 135. Some multiple strand chains or large pitch models will require a hammer and punch or a press to remove the pins.
B. Installation of Coversides
Diamond coversides are manufactured three different ways: (1) Slip Fit, (2) Modihed Press Fit, and (3) Full Press Fit. Modified and Full Press Fits require some patience and tools to assemble and/or disassemble.
C. Installation of Spring Locks and Cotterplns
After coversides have been installed, install spring locks or cotters (depending on chain design).
Avoid using bent or worn cotters or spring locks. Alter spring locks (or cotters) are installed, lightly
tap pin ends to position these parts snug against the coverside for additional support.

WHEN INSTALLING CHAIN DRIVES ON EQUIPMENT:
WARNING - You may be seriously injured if you attempt to install chain on equipment under power.
Shut off power and lock out gears and sprockets before attempting installation.

Once Installed, the chain drive must be guarded to prevent personal injury or property damage in the event the chain separates during operation. lf chain drive is not guarded, contact equipment manufacturer for recommendations on guarding before using equipment

Knowing more about how the chain is constructed may help in assembly and disassembly. Further information may be obtained by calling or writing Diamond Chain Company.

READ ASSEMBLY INSTRUCTIONS BEFORE INSTALLATION.
