Frames

250 Custom Pro-Street Frame

Made in USA

250 Wide Drop-Seat
LSD Softail Prostreet Frame

Specical Features include:

40 Degree Rake.
5" Stretch on Back Bone.
-2" Stetch on Single Downtube.
Single Heavy Duty Curved Downtube.
1-3/8" tube with 156 wall.
CNC Milled motor mount.
TIG welded at major points.
MIG welded on our new precision frame fixtures for accurate location & fitment.
Accepts any Harley-Davidson Evolution motor 88"-135".
Motor mounts.
Rear axle and covers included.

accepts any Harley-Davidson Evo Big Twin engine except Twin Cam 88
included rear axle, pivot bolts and hardware.

Frame includes a Manufacturer s Statement of Origin (MSO) for registration
(will be shipped separately for safety).
$3499 Retail.

Retail:$3499
plus tax.

Demon's Cycle Pro-Street built on a similar frame

Made in USA!

300 Wide Drop-Seat
RSD Softail Prostreet Frame

Specical Features include:

40 Degree Rake.
5" Stretch on Back Bone.
0" Stetch on Single Downtube.
Single Heavy Duty Downtube.
CNC Milled motor mount.
TIG welded at major points.
MIG welded on our new precision frame fixtures for accurate location & fitment.
Accepts any Harley-Davidson Evolution motor 88"-135".
Motor mounts.
Rear axle and plates included.

accepts any Harley-Davidson Evo Big Twin engine except Twin Cam 88
included rear axle, pivot bolts and hardware.

Frame includes a Manufacturer s Statement of Origin (MSO) for registration
(will be shipped separately for safety).
$3499 Retail.

Retail:$3499
plus tax.

Made in USA!

300 Wide Drop-Seat
RSD Softail Prostreet Frame

Specical Features include:

40 Degree Rake.
5" Stretch on Back Bone.
-2" Stetch on Single Downtube.
Single Heavy Duty Curved Downtube.
1-3/8" tube with 156 wall.
CNC Milled motor mount.
TIG welded at major points.
MIG welded on our new precision frame fixtures for accurate location & fitment.
Accepts any Harley-Davidson Evolution motor 88"-135".
Motor mounts.
Rear axle and covers included.

Retail:$3499
plus tax.

Demon's Cycle Pro-Street built on a similar frame

Made in USA!

250 Wide Drop-Seat
LSD ProStreet Frame

accepts any Harley-Davidson Evo Big Twin engine except Twin Cam 88
included rear axle, oil tank, billet oil cap.

Frame includes a Manufacturer s Statement of Origin (MSO) for registration
(will be shipped separately for safety).
$3499 Retail.

Retail:$3499
plus tax.

Made in USA!

200 Wide Drop-Seat
LSD ProStreet Frame

accepts any Harley-Davidson Evo Big Twin engine except Twin Cam 88
included rear axle, oil tank, billet oil cap.

Frame includes a Manufacturer s Statement of Origin (MSO) for registration
(will be shipped separately for safety).
$3499 Retail.

Retail:$3499
plus tax.

Made in USA!

Rigid Wide Drive Frame

This is a nice clean old school chopper rigid frame that handles perfect and is not too too big.
Brand new first quality Rigid Frame.
This USA made frame has a 34 degrees rake,
4"  downtube stretch,
1"  backbone stretch and accepts up to 210mm tire with a belt. This frame make a great bike.
Auction is for Frame with MSO
Accepts all Harley-Davidson 1985 - 99 EVO Engines + Transmissions
80" to 135"

Dimensions:

Rake of 34 degrees.
4" Stretch downtubes.
Tank mounts.
1026 DOM (Drawn Over Mandrel) steel tubing.
Legs are 1.25" O.D. with .125" thick wall.
Backbone is 1.500" O.D. with .187" thick wall.
Seat post is 1.500" O.D. with .187" thick wall.

Product ID = 3322

FAT TIRE 250mm SOFTAIL STYLE FRAME

SpecialFeatures include:

38 Degree Rake.
4 " Stretch on back bone
2 " Down tube stretch

Frame comes with rear axle, swingarm, pivot arm and MSO.

Accepts Harley-Davidson Evolution motor 1986-99 and any Evo-style engine up to 135": RevTech, S+S, Ultima, Merch, Patrick.

Notice! For safety reasons we ship MSO separately from the frame.
The purchaser of the frame should email us with the VIN # found on the frame
and his mailing address. We will ship the MSO immediately upon this conformation.

Custom motorcycle built by Demon's Cycle on similar frame

300 Wide Drop-Seat
RSD Softail Prostreet Frame

Specical Features include:

45 Degree Rake.
4" Stretch on Back Bone.
0" Stetch on Single Downtube.
Single Heavy Duty Downtube.
CNC Milled motor mount.
TIG welded at major points.
MIG welded on our new precision frame fixtures for accurate location & fitment.
Accepts any Harley-Davidson Evolution motor 88"-135".
Motor mounts.
Rear axle and plates included.

accepts any Harley-Davidson Evo Big Twin engine except Twin Cam 88
included rear axle, pivot bolts and hardware.

Frame includes a Manufacturer s Statement of Origin (MSO) for registration
(will be shipped separately for safety).
$3499 Retail.

Retail:$3499
plus tax.

200 Custom Pro-Street Frame

Made in USA

200 Custom Pro-Street Frame

Frame is made to accept Harley-Davidson Evolution motor or any custom Evo-style motors.

Accepts Wide 200-series tire
Full TIG welding
1"- diameter rear axle
38° degree rake
6" Out Stretch
2" Up Stretch
1-3/4" and 1-3/8" tubes
Left Side Drive
Adjustable transmission plate.
Bilet aluminum axle covers.
Comes with rear axle.

Made in USA
